Product Overview
PetroChina Jilin HDPE JHMGC100S is a high-molecular-weight bimodal PE100 pipe grade produced by PetroChina Jilin Petrochemical using Hostalen slurry technology and Z501 catalyst. It offers corrosion resistance, strong resistance to environmental stress cracking and rapid crack growth, good fusion welding and good sag resistance in large-diameter pipe.
Grade & Processing
Grade: JHMGC100S. Polymer family: high-density polyethylene (HDPE), PE100 pipe grade. Designed for pipe extrusion, including large-diameter pressure pipe.
Typical Applications
- Pressure-bearing water pipe
- Industrial pipe
- Large-diameter water-supply pipe
- PE100 gas-pipe raw material subject to project approval
Technical Data
| Property | Specification / measured value | Unit | Method |
|---|---|---|---|
| Coloured pellets | ≤ 20 | particles/kg | Product technical index |
| MFR, 190 °C/5.00 kg | 0.23 ± 0.03 | g/10 min | Product technical index |
| Density | 0.948 ± 0.002 | g/cm³ | Product technical index |
| Tensile yield stress | ≥ 20.0 | MPa | Product technical index |
| Tensile elongation at break | ≥ 400 | % | Product technical index |
| Notched Charpy impact, 23 °C | ≥ 20 | kJ/m² | Product technical index |
| Volatile content | ≤ 350 | mg/kg | Product technical index |
| MFR, 2.16 kg – measured | 0.060 | g/10 min | GB/T 3682-2000 |
| MFR, 5 kg – measured | 0.25 | g/10 min | GB/T 3682-2000 |
| MFR, 21.6 kg – measured | 6.7 | g/10 min | GB/T 3682-2000 |
| Density – measured | 0.9456 | g/cm³ | Ideal-gas-state-equation method |
| Charpy impact strength, 23 °C – measured | 26.3 | kJ/m² | GB/T 1043-1993 |
| Tensile strength – measured | 35.8 | MPa | TDS/article |
| Tensile yield strength – measured | 23.4 | MPa | GB/T 1040-1992 |
| Elongation at break – measured | 780 | % | GB/T 1040-1992 |
| Flexural strength – measured | 25.3 | MPa | GB/T 9341-2000 |
| Flexural modulus – measured | 1049 | MPa | GB/T 9341-2000 |
| Vicat softening point | 126 | °C | GB/T 1633-2000 |
| Moisture content, 200 °C | 29 | µg/g | Q/SY DS 0240 126-2007 |
| Oxidation induction time, 210 °C | 61.0 | min | GB/T 17391-1998 |
| Crystallinity | 49.9 | % | Q/SY DS 04 064-2005 |
| Number-average molecular mass, Mn | 17732 | — | GPC |
| Weight-average molecular mass, Mw | 268597 | — | GPC |
| Molecular-weight distribution, D | 15.15 | — | GPC |
Be the first to review “PetroChina Jilin HDPE JHMGC100S”
Related products
HDPE
SABIC HDPE F00952J: HDPE grade F00952J with applications and technical data from the supplied manufacturer document.
Polypropylene
Borouge Borstar RA150E: PP-R random copolymer grade RA150E with applications and complete supplied technical data.
Sinopec HDPE HD5502ZK: HDPE grade HD5502ZK with applications and technical data from the supplied manufacturer document.
HDPE
SABIC HDPE B5428 is a medium-molecular-weight blow-moulding HDPE grade for household and industrial chemical containers.
HDPE
SABIC HDPE M200056: HDPE grade M200056 with applications and technical data from the supplied manufacturer document.
PetroChina Guangdong HDPE 23050: HDPE grade 23050 with applications and technical data from the supplied manufacturer document.
SIBUR HDPE HD03490 NP: HDPE grade HD03490 NP with applications and technical data from the supplied manufacturer document.
PetroChina Guangdong HDPE DGDZ-6095: HDPE grade DGDZ-6095 with applications and technical data from the supplied manufacturer document.
Reviews
There are no reviews yet.
